AIR-MT8K LCD HDMI Matrix Switcher
| Category | Specification |
|---|---|
| HDMI Port | Signal Standard: HDMI 1.4 Backward Compatible; Resolution: VESA Standard, ≤3840×2160p@30Hz; Interface Type: HDMI-A Socket; Quantity: 8× Input & 8× Output |
| Net Ethernet Port | Interface Type: RJ45; Web Version Upper PC Control Can Be Achieved By Connecting The Computer Through Ethernet Cable |
| USB Port | USB-B, Can Upgrade The Device Programs Through USB Disk |
| RS232 Serial Port | By The Upper-PC Protocol To Control, RS232 Has Loop-out Function, Which Can Be Cascaded And Controlled Multiple Devices |
| Extended Port | EXT, ANT Extended Interface, Not Enabled |
| Performance | |
| Switching Method | Seamless Switching, Audio & Video Sync Output |
| Device Language | Standard Version Is English, Other Languages Require Remarks |
| General Specifications | |
| Power Supply | Mean Well Brand Built-in, 100~240V AC, 50~60Hz |
| Temperature | Storage: T: -40°C ~ +80°C, H: 10% ~ 90%, Non-condensing; Working: T: 0°C ~ +60°C, H: 10% ~ 90%, Non-condensing |
| Machine Size | 485 mm (L) × 320 mm (W) × 77 mm (H) |
| Packing Size | 515 mm (L) × 375 mm (W) × 100 mm (H) |
| Product Weight | Gross Weight: 4.0 kg |
| Package Weight | Volume Weight: 5.0 kg |
| Warranty | 1 Year; Note: All Rated Voltages Are On Average ±10% |
| Packing List | |
| Standard | Power Cable ×1, Certificate ×1, Warranty Card ×1 |
| Model | AIR_MTX_8x8 |
| Description | Standard Model |
| P/N | PN202411008 |
