Aircom AWD-T352D Conference Delegate Unit

The Aircom AWD-T351D delegate unit was developed by our R&D people with over 10 years of experience in conference systems. The scratch-resistant back-lit glass control panel is unique in design. CAT5 cable port is popular for its lots of advantages. Special loop ring connection methods promise the reliability and robustness of our system are not affected by any broken units during the conference.

Aircom AWD-T351D Conference Delegate Unit

● Compliance with IEC 60914, GBT 15381-94
● The unique AUDIO-LINK digital ring network technology achieves full-digital signal transmission and processing, completely avoiding RF interference from a cell phone or similar devices.
● Single CAT5e cable transmits 64 channels of audio and various information.
● High fidelity sound by zero loss audio transmit technology, 48K audio sampling frequency, 20Hz~20KHz response frequency
● “Hand-in-Hand-Loop-Network” connection makes the system always work perfectly no matter changing discussion units or having any malfunctioned units
● This system automatically assigned to each unit independently ID to avoid duplicate ID conflict
● Limiter to prevent the sound from suddenly becoming loud or low; noise gate of the human voice can be identified; AGC (Automatic Gain Control)/AFC (Adaptive

● Feedback Cancellation)/ANC (Active Noise Control)/Mix (Auto-Mix) technology
● Hot-swap for any system unit, and the controller has an auto-recovery function
● Precise cardioid directional microphone capsule with anti-wind microphone foam, with a two-color LED indicator
● Button for MIC ON/OFF, Priority & Apply Answer button for chairman unit
● Built-in high-fidelity speakers, automatically mute to prevent howling when pressing MIC ON
● Headset interface on both sides with volume adjust
● Discussion modes:
“OPEN” Free for all, limited by the active units setting by controller, “VOICE” Unit activated by voice, “OVERRIDE” First in First out, “PTT” Keep pressing a button when speaking, “APPLY” To apply then to speak, “ALL” Free to speak for all people
● Work with our HD camera and video matrix switcher, it applies the camera auto-tracking function.
