AW CAT 203 Camera Auto Tracking Processor

●4 HD/3G SDI input, 1+1 HDMI output.
●4*1+1 seamless scaler switcher, maximum supported output resolution is 1080P@60Hz
●Seamless switching, no jitter, no blank screen.
●Adjustable image freezing function

Description

It’s a auto-tracking camera controller, can support both traditional preset position camera tracking as well as new infrared located tracking function. It has a built-in 4*1 matrix switcher to process different signals and with the function of image freezing. Besides, it will manage several cameras at the same time.

Features

  • 4 HD/3G SDI input, 1+1 HDMI output.
  • 4*1+1 seamless scaler switcher, maximum supported output resolution is 1080P@60Hz
  • Seamless switching, no jitter, no blank screen.
  • Adjustable image freezing function ( freezing time from 1 to 6 seconds, freezing time can not be less than 1 second or freezing function would be turned off).

Functions

  • Turn on/off the channel number indicators
  • 4*1 seamless scaler switcher, maximum supported output resolution is 1080P@60Hz,
  • Seamless switching, no jitter, no blank screen.
  • Adjustable image freezing function ( freezing time from 1 to 6 seconds, freezing time can not be less than 1 second or freezing function would be turned off).

Interfaces

4x SDI input

2x HDMI-A

1x female DP9

Technical Parameters

Input

Signal format/Quantity…………………………:SDIx4

Connector…………………………BNC female connectors

Pixel bandwidth…………………………165MHz

Video format …………………………270Mbps SDI, 1.485Gbps HD-SDI and 2.97Gbps 3G-SDI

Support resolution…………………………1280×720@50Hz;1280×720@60Hz;

                           1920×1080@25Hz;1920×1080@30Hz

                           1920×1080@50Hz;1920×1080@60Hz

Transmission distance …………………………3G-SDI ≤100m with certified SDI professional cable.

Output

Signal format/Quantity…………………………HDMIx2

Connector…………………………HDMI-A connectors

Pixel bandwidth…………………………165MHz

Support resolution………………………… 1280x720x50Hz;1280x720x60Hz;

1920x1080x50Hz;1920x1080x25Hz;

1920x1080x30Hz;1920x1080ix50Hz;

1920x1080x60Hz;1920x1080ix60Hz;

Transmission distance…………………………HDMI≤7m with certified HDMI professional cable.

Control

RS232 control

Front panel control

Mechanical

Dimensions (L x W x H) …………………………483 x 260 x43.6 mm

Weight…………………………3kg

Color…………………………black
